Model number

/

2BJY4

structural style

/

Hanging type

Supporting power range

kW

66.2～88.2

Working state external dimensions (length x width x height)

mm

2500×1807×1396

Operation speed range

km/h

6～8

Hourly productivity of homework

hm2/h

1.4～2.2

row spacing

mm

700(400～700Adjustable)

Number of work lines

line

4

Working breadth

mm

2800（1600～2800Adjustable）

Type of seeder

/

Finger clip style

Number of seeders

个

4

Driving method of seeder

/

motor drive

Type of fertilizer feeder

/

Outer groove wheel type, non-metallic materials

Number of fertilizer feeders

个

4

Driving method of fertilizer feeder

/

motor drive

Seed/fertilizer box capacity

L

Species 30L×4；fertilizer 340L

Displacement adjustment method

/

Electric

Transmission mechanism type

/

Motor+shaft drive

Trencher type

/

Sowing: Plow type; Fertilization: Plow type

Number of trenchers

个

Sowing: 4; Fertilization: 4

Depth adjustment range of trencher

mm

Sowing: 30-100; Fertilization: 60-130

Ground wheel type

/

Rubber wheels

Ground wheel diameter

mm

400

Range of ground wheel height adjustment

mm

0～130

Types of components for stubble breaking and ridge cleaning work

/

/

Fan model name

/

/

Fan impeller diameter

㎜

/

Fan speed

r/min

/

Fan pressure

MPa

/

Type of soil cover

/

/

Type of suppressor

/

Rubber wheels
